Product Description:
High Pressure Diaphragm Seal is a reliable and efficient sealing solution designed to meet the requirements of various high-pressure applications. This sealant comes with a process connection of G1/4 to G2, and is available in a wide range of accuracy classes including 0.5, 0.2 and 0.1. It also offers multiple output signals such as 4-20mA, 0-10V and 0-5V, and can be used for gauge and absolute process pressure. The housing of this product is made of stainless steel, providing superior strength and durability. This high-pressure diaphragm seal is designed to ensure that the pressure is contained within the system, and that the process and instrumentation remain safe and secure. It is ideal for a variety of applications due to its high-pressure sealing capability and superior performance.
Features:
- Product Name: High Pressure Diaphragm Seal
- Protection Class: IP67
- Seal Type: Diaphragm
- Accuracy Class: 0.5, 0.2, 0.1
- Process Pressure: Gauge, Absolute
- Pressure Range: 0-1000 Bar
- High-Pressure Sealing
- High-Pressure Sealing
- High-Pressure Diaphragm Seal
Technical Parameters:
| Property |
Value |
| Housing |
Stainless Steel |
| Process Media |
Liquid, Gas |
| Seal Type |
High-Pressure Diaphragm |
| Process Temperature |
Ambient, Media |
| Output Signal |
4-20 mA, 0-10V, 0-5V |
| Process Connection Size |
1/4" |
| Fill Fluid |
Glycerin, Silicone Oil |
| Temperature Range |
-50 To +200 °C |
| Process Connection |
G1/4 To G2 |
| Protection Class |
IP67 |
| High Pressure Sealant |
High-Pressure Sealing System |
Applications:
High Pressure Diaphragm Seal, with the brand name of HEAD, is originated from China. It provides reliable sealing under high-pressure conditions and is widely used in industrial applications. It has G1/4 to G2 process connection that can handle liquid and gas media with great accuracy. It is available in three levels of accuracy: 0.5, 0.2, and 0.1, and the output signal is 4-20mA, 0-10V, and 0-5V. The temperature range is -50 to +200 °C, making it suitable for a wide range of applications. Moreover, it features excellent high-pressure sealing performance and is ideal for industrial applications that require reliable high-pressure sealing.
Customization:
Customized High Pressure Diaphragm Seal from HEAD
Our High Pressure Diaphragm Seal is a reliable and high-precision sealing solution for the most demanding applications. It is made of stainless steel and can withstand pressures up to 725 psi. It is ideal for use in high-pressure sealing, high pressure sealant, and high-pressure diaphragm sealing.
The High Pressure Diaphragm Seal features a brand name of HEAD, originating from China. It is designed for use with pressures ranging from Gauge to Absolute and temperatures from Ambient to Media. It is available with a G1/4 to G2 process connection and has an accuracy class of 0.5, 0.2, or 0.1.
Support and Services:
High Pressure Diaphragm Seal Technical Support and Service
- Assistance with selecting the proper seal for the application.
- Access to technical data concerning pressure, temperature, chemical compatibility, etc.
- Expertise in troubleshooting seal issues.
- Training programs for seal installers.
- Maintenance and repair of seals.
- Installation of seals.
- Assistance with custom designs.
Packing and Shipping:
High Pressure Diaphragm Seal Packaging and Shipping:
- Packaging: High Pressure Diaphragm Seal are packaged in strong cardboard boxes, which are then placed in larger cardboard boxes for shipping.
- Shipping: High Pressure Diaphragm Seal are shipped by courier, air freight or sea freight depending on the size and quantity of the order.
